What is a Hanging Wind Sifter?
A Hanging Wind Sifter for sale, also known as a Hanging Air Separator or Suspended Windshifter, is a compact air separation machine designed to be installed above conveyors or directly connected to the discharge end of crushers and shredders. It uses adjustable airflow to separate lightweight materials from heavy materials based on density and aerodynamic characteristics, making it ideal for space-limited recycling plants and existing sorting lines.
The FXD Series Hanging Wind Sifter removes lightweight fractions such as plastic film, paper, fabric, foam, and wood chips, while allowing heavy materials including concrete, stone, glass, and metal to continue for further processing. It is commonly integrated with crushers, shredders, vibrating screens, trommel screens, magnetic separators, and optical sorting equipment to improve material purity and recovery efficiency.
Applicable Materials
The wind sifter is designed for air separation of lightweight fractions from pre-processed mixed waste streams, including C&D waste, MSW, industrial waste, and RDF materials. It removes plastic film, paper, fabric, foam, wood chips, and other light materials from heavier fractions such as concrete, stone, glass, and non-ferrous impurities after crushing or screening processes.
Working principle
The FXD hanging wind sifter for sale uses adjustable airflow to separate lightweight fractions from heavy materials in mixed waste streams. After entering the separation chamber, materials are classified by their aerodynamic characteristics, with light materials carried away by airflow and heavy materials discharged for further processing. The following steps show how the FXD Series achieves efficient air separation.
Material Feeding: Mixed materials enter the separation chamber evenly through conveyors for efficient airflow separation.
Controlled Airflow Generation: Adjustable airflow is generated by the fan to create stable separation conditions.
Lightweight Material Separation: Lightweight fractions are lifted by airflow while heavy materials continue downward.
Light Fraction Collection: Separated light materials are collected for recycling or further processing.
Heavy Material Discharge: Heavy materials are discharged to downstream equipment for additional sorting.
Specifications
FXD series hanging wind sifter is available in multiple models to meet different processing capacity requirements. The main specifications include air pressure, airflow volume, motor power, and processing capacity, allowing users to select the suitable configuration based on material characteristics and recycling line requirements. Detailed technical parameters are listed below.
| Model | Wind Pressure (Pa) | Air Volume (m³/h) | Power (kW) | Capacity (m³/h) |
| FXD06 | 790–502 | 3800 | 5.5 | 20–50 |
| FXD08 | 20–80 | |||
| FXD10 | 20–100 |
Advantages
The wind sifter for sale is designed for efficient lightweight material separation with a compact hanging structure, adjustable airflow system, and flexible integration into recycling lines. Based on different material characteristics and project requirements, Xinzhongyi ECO provides reliable equipment solutions for various waste sorting applications.
Applications
The FXD Wind Sifter for Sale is designed for removing lightweight materials from mixed waste streams through adjustable airflow separation. It is widely used in recycling plants to separate plastic film, paper, wood, textiles, and other light fractions from heavier materials, improving sorting efficiency and recovery quality.
As a direct manufacturer, Xinzhongyi ECO supplies customized wind sifter equipment according to material characteristics, processing capacity, separation requirements, and recycling project conditions.
Custom Hanging Wind Sifter Solutions
Xinzhongyi ECO provides customized hanging wind sifter solutions for waste recycling projects, covering process design, equipment selection, manufacturing, and installation support. The wind sifter for sale can be integrated into MSW sorting plants, C&D waste recycling lines, RDF production systems, and other resource recovery projects, supporting both standalone equipment supply and complete recycling plant solutions.
Custom Options Include:
- Material type and composition
- Processing capacity (t/h or m³/h)
- Feed size and particle distribution
- Moisture content of the material
- Required separation results and target recovery rate
- Installation space and layout conditions
How to Choose the Right Hanging Wind Sifter?
Choosing a hanging wind sifter starts with understanding the waste material. Different materials require different airflow settings and separation designs. Before selecting equipment, Xinzhongyi ECO engineers check the material composition, lightweight fraction content, moisture level, and feed size to determine the required separation performance.
The machine capacity should match the actual processing demand, usually measured in t/h or m³/h. The wind sifter also needs to fit the existing production line, including screen equioments, shredders, and belt conveyors. For retrofit projects or plants with limited floor space, the hanging design allows installation above conveyors and helps reduce layout changes. Xinzhongyi ECO selects the suitable model and airflow configuration according to each project’s material and site conditions.
Hanging Wind Sifter Manufacturer & Supplier
Xinzhongyi ECO is a professional hanging wind sifter manufacturer and supplier with 16+ years of recycling equipment manufacturing experience, helping customers remove plastic film, paper, wood, and other lightweight materials from mixed waste streams. We provide customized equipment configurations, airflow design, and integration solutions for MSW sorting, C&D waste recycling, RDF production, and industrial waste processing based on different material characteristics and project requirements.
As a direct manufacturer, Xinzhongyi ECO supports customers from equipment selection and process design to manufacturing and installation guidance. With 3 production bases and over 60 patented technologies, we supply both standalone hanging wind sifters and complete recycling plant solutions, helping customers improve separation performance, material recovery quality, and equipment reliability.
FAQ
A hanging wind sifter separates lightweight materials such as plastic film, paper, wood, and textiles from mixed waste streams. It is widely used in MSW sorting, C&D recycling, and RDF production.
It uses controlled airflow to separate lightweight fractions from heavier materials, with adjustable airflow settings for different materials.
Selection depends on material type, capacity, feed size, moisture content, separation targets, and installation conditions.
The price depends on capacity, airflow configuration, material characteristics, customization requirements, and project scope.
Yes. It can be installed above conveyors and integrated with screens, shredders, and other sorting equipment.
With 16+ years of recycling equipment experience, Xinzhongyi ECO provides customized equipment selection, manufacturing, and installation support.
